C0049NDI20000
El código C0049NDI20000 será válido a partir de marzo de 2025. Aún puedes continuar con este código o utilizar el código C00514WHNDI válido hasta marzo de 2025.Indoor / Flex Lights
LED Strip | 1 topLED 192 W DC 48 V
9.6 W/m | 993.1 Lm/m
| IP | IP20 |
|---|---|
| Óptica | Diffused |
| CCT | 4000 K |
| CRI | 90 |
| Lumen de luminaria | -- |
| Acabados | Blanco |
| Posición de instalación | Pared, Techo |
| Control | |
| Tipo de fuente | topLED |
Descripción técnica
Single emission led strip for indoor application. The natural white LED light source with a diffused light distribution is composed of 2600 stripled LEDs with CCT of 4000 K and a CRI 90; the source luminous flux is 21647 lm, with a 112.7 lm/W nominal luminous efficacy.
The device body is made of technopolymer and features a white finish. The ingress protection degree is IP20; the total weight is of 1.6 kg. The power supply driver is not provided and is to be ordered separately.
The total absorbed power is 192 W. The power supply cable is included and features a 0.2 m length.
The device features protection class III and can be wall lights or ceiling-mounted.
Compliant with the EN 60598-1 standard and its specific provisions.
Electrónica
Código 99784
Stormshield - On/Off Driver 48V 150W 3.13A | Switching Driver 180~295V AC / 255~417V DC 60 W
| Familia | Driver de conmutación |
|---|---|
| IP | IP67 |
| Operation | CV |
Código 99785
Stormshield - On/Off Driver | On/Off Driver 100~305V AC / 142~431V DC 240 W
| Familia | On/Off Driver |
|---|---|
| IP | IP65 |
| Operation | CV |
Código 83177
Lumiquad - Mono CV DMX/RDM 1ch - 1-78 W DC - 6.5A 12V / 1-156 W DC 6.5A 24V / 1-312 W DC - 6.5A 48V | Push and Simply Dim Controller
| Familia | Controller |
|---|---|
| IP | IP10 |
| Operation | CV |
Código C-E400003
DALI-2 PUSH Driver - 1-150 W DC stripLED - 3.2A 48V 150W | Push and Simply Dim Controller
| Familia | Controller |
|---|---|
| IP | IP67 |
| Operation | CV |
