Ribbon PRO
C0024MDI05000
Der Code C0024MDI05000 wird ab März 2025 gültig sein. Sie können mit diesem Code fortfahren oder den Code 82156 verwenden, der bis März 2025 gültig ist.Indoor / Flex Lights
LED Strip | 640 topLED 33.5 W DC 24 V
6.7 W/m | 927.6 Lm/m
| IP | IP20 |
|---|---|
| Optisch | Diffused |
| CCT | 2700 K |
| CRI | >90 |
| Leuchten Lichtstrom | -- |
| Einbaulage | Wand, Decke |
| Kontrolle | |
| Quelle Typ | topLED |
Technische Beschreibung
Single emission led strip for indoor application. The super warm white LED light source with a diffused light distribution is composed of 640 topled LEDs with CCT of 2700 K and a CRI >90; the source luminous flux is 4638 lm, with a 138.4 lm/W nominal luminous efficacy.
The device body and features a white finish. The ingress protection degree is IP20; the total weight is of 0.09 kg. The power supply driver is not provided and is to be ordered separately.
The total absorbed power is 33.5 W. The power supply cable is included and features a 0.3 m length.
The device features protection class III and can be wall lights or ceiling-mounted.
Compliant with the EN 60598-1 standard and its specific provisions.
